Description
Order Information
| EAN Number | 5702663231429 |
|---|
CHARACTERISTICS
| Output level CTB @ 60 dB IMD | dBμV | 105 dBμV |
|---|---|
| Output level CSO @ 60 dB IMD (42 ch) flat | dBμV | 102 dBμV |
Frequency Range
| Frequency range | MHz | 47…1006 MHz |
|---|
GAIN
| Gain | dB | 30 (@1006MHz) dB |
|---|---|
| Gain forward – Interstage | dB | 0 / -3 fixe dB |
| Noise figure | dB | 4.5 dB |
LOSS
| Attenuation | dB | 0…20 dB |
|---|---|
| Attenuation – interstage | dB | 3 fix dB |
Electrical
| Linearity | dB | ± 1.0 dB |
|---|
OPERATIONAL
| IP Housing protection class | IP 20 |
|---|---|
| Insulation Class | II |
Connectors
| RF connector – Test point input: bi-directional | dB | -20 dB |
|---|---|
| RF connector – Test point output: directional | dB | -20 dB |
MECHANICAL
| Weight (kg) TB(D) | kg | 0.65 kg |
|---|---|
| Product Height | mm | 60 mm |
| Product Width | mm | 148 mm |
| Product Depth | mm | 75 mm |
| Packaging Height | m | 0.071 m |
| Packaging Width | m | 0.230 m |
| Packaging Depth | m | 0.130 m |
| Packaging Volume | m3 | 0.002 m3 |
| Net Weight | kg | 0.482 kg |
| Tara Weight | kg | 0.103 kg |
| Total Weight | kg | 0.585 kg |
